This post is a step by step description for making magnetic wrist joints (M00220), used as an option with the HPA-1 (Humanly Posable Armature) Kit.

.

Hands with Magnetic Wrist Joints.

Cut 10 fingers out of cotton-covered finger wire, 32 Ga.
Put them into the piece of round brass tube 5/32″ (opposable thumb wire from the opposing end).

. .

Flatten the tube with long nose pliers and, for good measure, carefully pinch it a few times with wire cutter.
Carefully, don’t cut them off. Set the hand on a shorted ball screw. Pinch with pliers to tighten the tube around the screw.

. .

.
Here are the parts that make the magnetic wrist joint, from top to bottom:
round brass tube 5/32″ (hand module)
brass connector M2x10 mm
8 mm countersunk magnet
The hand.
Cold Weld epoxy is used to secure hand module, brass connector and ring magnet.

..
..

***************************
Sculpting hands.

Paint wire with Translucent Liquid Sculpey on cat tongue brush.
Make little sausages.

. .

The sausage fingers should be the same width as on the reference photo.

. .

Make indentations where the fingers bend with the X-acto knife.
Make nails on the other side with fingernail tools.

. .
Bake.
Make small cuts where finger knuckles are.

. .

Bend fingers (break clay).
Paint fingers with Translucent Liquid Sculpey

. .

Put clay on the palm and sculpt the hands with a hook micro tool, cat tongue brush, fine point tip rubber tool.
Finger ring palette is helpful to keep the clay and liquid clay close to the sculpting area.

. .
Finish, bake and paint with Genesis paints, at the same time you paint the face. For reference use your own hands.

..
